32650 Cell LiFePO4 Lithium Battery Pack 24V 100AH Solar Energy Storage

Ask Lasest Price
Brand Name :	LEADYO
Model Number :	LP24V100
Certification :	UN38.3, CE,MSDS,UKCA
Price :	Negotiable
Payment Terms :	L/C, D/A, D/P, T/T, Western Union, MoneyGram,Online
Supply Ability :	60Mwh
Delivery Time :	15-45 Days

Add to Cart

Product Details
Company Profile

32650 Cell LiFePO4 Lithium Battery Pack 24V 100AH Solar Energy Storage

32650 Cell Solar Energy Storage LiFePO4 Lithium Battery pack 24V 100AH

Lithium Iron Phosphate Battery 24V 100Ah

Nominal Voltage 25.6 V

Nominal Capacity 100 Ah

Energy 2560 Wh

Resistance ≤30 mΩ @ 50%

SOC Self Discharge <3% / Month

Features

5000 cycles @80% DoD for effectively lower total of ownership cost;
No maintenance batteries with stable chemistry;
Lithium batteries provide more Wh/Kg while also being up to 1/3 the weight of its SLA equivalent.
Built In Smart BMS with Full safety protected function

ELECTRICAL SPECIFICATIONS		MECHANICAL SPECIFICATIONS
Nominal Voltage	25.6V	Terminal Type	M8
Nominal Capacity	100Ah	Weight	26kg
Nominal Energy	2560Wh	Case Dimension(LWH)	520232217mm
Internal Resistance	≤30 @50% SOC	Case Type	ABS
Capacity	@20A: 300minutes(5hours)	Cell type / Chemistry	LiFePO4
Self Discharge	5% /per month	LCD or Bluetooth Function	Optional
Maximum In Series	2PCS	BMS:low voltage,high voltage,over temperature,
Maximum In Parallel	No limit	Over current,short-circuit protection .etc
Discharge Current and Voltage Specifications		Charge Current and Voltage Specifications
MAX Continuous Discharge Current	100A	Max Charge Current	100A
Peak Current	300A	Recommended Charge Current	20A - 50A
Discharge pulse current	500±50A (31±10ms)	End of Charge voltage	28.8V±0.2V
BMS Low Voltge Cut-off	20V (2.0V±0.05v) pc)	Balancing current	Auto start
Short Circuit Protection	200-800 µs Auto recover or charge release	Balancing Voltage	3.6V±0.05v pc
Temperature Ranges		COMPLIANCE SPECIFICATIONS
Discharge Temperature	-20～+65℃	Certifications	CE for Battery Pack
Charge Temperature	-20～+45℃		UL1642 & IEC62133 & BIS for cells
Storage Temperature Range	-20～+45℃		UL1642 & IEC62133 & BIS for cells
BMS High Temperature Protection	90℃	Shipping classification	UN 3480
Battery High Temperature Protection	60℃

FAQ

Q1. What is the biggest differene between your battery and other suppliers:

A: Safest with longer lifespan.

Q2. Why your battery is safer than others?

A: We adopt Bolt in structure, it is strongest structure with most advanced technology involved.

B. We only focus on LiFePO4 Battery pack, made of UL certificated battery cell.

C. Integrated BMS to monitor tempeature, voltage, current to realize over voltage protection, over current protection, over temperature protection, short circuit protection, Reverse Polarity protection,

Q3. Why does your battery ensure longer lifespan than others?

A: With more than 10 years experiences in LiFePO4 Battery pack, unrivalled technical capacity ensured.

B. Olivine LiFePO4 Structure(Most stable structure)

C. Single cell protection(Unique in China)

Q4. How about your batttery delivery time?

A: 1-25 workdays after receiving your advance payment. The specific delivery time depends on the items and the quantity of your order.

Q5: How about your warranty?

A: 2 years warranty

Q6.Is this product safe?

A:Passed the overcharge, over discharge, over temperature, short circuit, acupuncture and other safety tests, no fire, no explosion at any circumstance;price to ensure our customers benefit ;
