20Ah 12V Lifepo4 Battery With BMS Replace Sealed Lead Acid Battery

Ask Lasest Price
Brand Name :	LEADYO
Model Number :	LP12V020
Certification :	UN38.3, CE,MSDS,UKCA
Price :	Negotiable
Payment Terms :	L/C, D/A, D/P, T/T, Western Union, MoneyGram,Online
Supply Ability :	60Mwh
Delivery Time :	15-45 Days

Add to Cart

Product Details
Company Profile

20Ah 12V Lifepo4 Battery With BMS Replace Sealed Lead Acid Battery

12V 20Ah LiFePO4 Battery with BMS replace sealed lead acid battery

Lithium Iron Phosphate Battery 12V 20Ah

Nominal Voltage 12.8V

Nominal Capacity 20 Ah

Capacity @ 4A 300 min

Resistance ≤30 mΩ @ 50%

SOC Self Discharge <3% / Month

Balancing function

With Smart BMS has the over charge, over discharge, over current, short circuit, Over Temperature protection and balance function.

Features:

LiFePO4 12.8V 20Ah Lithium Batteries
With high lifespan: from 5000 cycles to several tens of thousands
BMS (Battery Management System) built into the case: maximizes battery life AND secures battery life
Excellent temperature hold (-20 to 60 degrees Fahrenheit)
Flexible system: no limit in parallel and 4 in series
Weight gain > 50% and 40% reduced footprint compared to lead batteries
Certification: CE, MSDS, UN 38.3

ELECTRICAL SPECIFICATIONS		MECHANICAL SPECIFICATIONS
Nominal Voltage	12.8V	Terminal Type	T3
Nominal Capacity	20Ah	Weight	2.5kg
Nominal Energy	256Wh	Case Dimension(LWH)	18077170mm
Internal Resistance	≤30 @50% SOC	Case Type	ABS
Capacity	@4A: 300minutes(5hours)	Cell type / Chemistry	LiFePO4
Self Discharge	5% /per month	LCD or Bluetooth Function	Optional
Maximum In Series	4PCS	BMS:low voltage,high voltage,over temperature,
Maximum In Parallel	No limit	Over current,short-circuit protection .etc
Discharge Current and Voltage Specifications		Charge Current and Voltage Specifications
MAX Continuous Discharge Current	20A	Max Charge Current	20A
Peak Current	40A	Recommended Charge Current	4A - 10A
Discharge pulse current	50±5A (31±10ms)	End of Charge voltage	14.4V±0.2V
BMS Low Voltge Cut-off	10V	End of discharge voltage	10V
Short Circuit Protection	200-800 µs Auto recover or charge release	Balancing Voltage	3.6V±0.05v pc
Temperature Ranges		COMPLIANCE SPECIFICATIONS
Discharge Temperature	-20～+65℃	Certifications	CE for Battery Pack
Charge Temperature	-20～+45℃		UL1642 & IEC62133 & BIS for cells
Storage Temperature Range	-20～+45℃		UL1642 & IEC62133 & BIS for cells
BMS High Temperature Protection	90℃	Shipping classification	UN 3480
Battery High Temperature Protection	60℃

FAQ

Q. Are you factory or trade company?

A:We ara leading battery manufacturer in China,Is a high-tech enterprise, specializing in R&D and marketing of Lithium rechargeable battery products.

Q. Can I print my LOGO on it?
A: YES, LOGO/sticker/OEM/ODM welcomed

Q. Can your battery be wired in series or parallel?
A: YES,YOU can connect up to ANY of these batteries in parallel. For series, suggest up to 48V.

Q. What warranty do I have?
A: Warranty: 3 years, we would provide repair or replacement with the warranty period.if any quality problems on our side in this period, Please show us video or photos for confirm before we sent solution.
